Specifications:

Bar diameter…….. 5mm to 67mm (0.196” to 2.637”)

Max. bar length…………………… 3,800mm (150")

Magazine rack capacity…………… 279.4 mm (11")

Magazine rack angle (adjustable)………….. 6° - 20°

Max. remnant length……………….. 530mm (20.8")

Bar loading cycle time (approx. for 12' bars).. 35 sec.

Max. feed force (adjustable)……….. 750 N (169 lb.)

Oil capacity……………………….. 80 liters (22 gal.)

Electrics…………………………….….. 3/60/230/400

Power consumption……………..... 2.5kW/3.125 kVA

Control voltage………………………………...... 24V

Compressed air supply……………….. 6 bar (90 psi)

Compressed air usage..... ~10 liters per loading cycle

Dimensions (approx.)……………..… 187"L x 31"D

Height (Open/Closed)…………………..… 61.5"/51"

Weight (approx. w/o oil)……….. 2,900 kg (6,380 lb.)

Equipped with:

Hand-held electronic control

Left-hand feed

(1) Channel set in machine

Nose piece

Miscellaneous collets

Hydraulic tank & pump

Manual

**LOW USAGE**
