Specifications:

Travels (X/Y/Z)…………………….….. 120"/60"/3.9"

Cutting area……………………………....... 48" x 96"

Cutting capacity;

  Mild steel…………..…  0.028" - 0.25" @100% DC

  Stainless steel… 0.028" – 0.187" w/ Quick Silver Process

  Aluminum….. 0.028" – 0.187" w/ Quick Silver Process

Cutting current………………………… 12 – 40 amps

Cutting speed range……………….…... 40 – 180 ipm

Min. Kerf width……………………………....... 0.06"

Positioning accuracy……………………… +/- 0.004"

Machine (CNC) electrics…... 1/50-60/120v/1.8 KVA

Plasma electrics……….…. 3/50-60/200-230/22 KVA

Floor space (approx.)…………………......…. 7' x 14'

Weight (approx.)……………………….....… 3,200 lb.

Equipped with:

Komatsu control system w/ display, keypad & joystick

KCT G940 – version 1 power supply

4' x 8' Part support grid

Open bridge torch carrier

Oxygen or nitrogen gas able

Down draft exhaust with hose

Dual rack/pinion drive w/ brushless motors & THK ways

Inner-logic RSVP 101 torch height control

Liquid self-contained torch cooling

On casters

Manuals

Miscellaneous consumables
