Specifications:

Table size……………………………... 19.7" x 35.4"

Max. weight of workpiece………………..… 1,000 lb.

X-axis travel……………………………….…….. 30"

Y--axis travel…………………………………….. 20"

Z-axis travel…………………………………….... 20"

Min/max spindle to table………………… 3.5"/23.5"

Rapid traverse(toolroom/production)… 400/1,000 ipm

Throat depth…………………………………... 18.25"

Spindle taper……………………………..…. CAT-40

Spindle speed range………………… 50 – 8,000 rpm

Max. tool weight……………………………….. 15 lb.

Max. tool diam………………………………… 3.14"

Spindle motor (peak/continuous)………..…. 15/10 Hp

Electrics…………………………...………… 3/60/208

Air required…………..……………… 90 psi - 2.5 cfm

Dimensions (approx... 97" x 135" x 106.5"H (max)

Weight (approx.)…………………………..… 8,360 lb.

Equipped with:

ProtoTRAK RMX CNC control

Remote stop/go switch

16-Station automatic tool changer

Electronic handwheels for manual X & Y movement

Electronic handle for manual Z-axis movement

4th Axis rotary table w/8" 3-jaw chuck and tail stock

DXF file converter

Parasolid file converter

TRAKing

Advanced features w/ Verify

Coolant system

Chip auger
